Technical information
Available in 3 versions:
- S for presentations of 50 to 150mL (300-400 bottles per minute)
- M for presentations of 150 to 650mL (300-400 bottles per minute)
- L for presentations from 500ml to 1500L (5-10 bottles per minute)
Model: | VOLMS-_ |
DimensionsS | 250 x 800 x700 mm |
Dimensions M | 400 x 950 x 900mm |
Dimensions L | 510 x 1300 x 1200mm |
Weight S | 20 kg approximately |
Weight M | 60 kg approximately |
Weight L | 80 kg approximately |
Entry and recirculation port | 1-1/2” Clamp |
Electrical specifications | 110 VAC 1F 60Hz |
Material | Stainless Steel 304 |
Cycle counter display | Optional |
Pneumatic specifications | 6 bar |
Air flow | 100 L |
Filling temperature | 40°C |
